Perfect Pipe Joints in Seconds (Shrinkwrap Method)

Summary

Key Points

• —Begin by adding a cylinder, adjusting its radius and vertices, applying scale, and setting Shade Auto Smooth. 0:44
• —Hollow out the cylinder by deleting its top and bottom faces, then add a Solidify modifier for thickness, naming it 'pipe_1'. 0:49
• —Duplicate 'pipe_1' to create 'pipe_2', scale and rotate it, then extract an edge loop from 'pipe_2' to create a separate 'circle' object, removing its Solidify modifier. 1:35
• —Apply a Shrinkwrap modifier to the 'circle' object, setting the target to 'pipe_1' and the wrap method to 'Project' along the appropriate axis. 2:17
• —Apply the Shrinkwrap modifier, then join the 'circle' and 'pipe_1' objects into a single mesh. 2:56
• —Add loop cuts to 'pipe_1' around the 'circle' area, then delete the faces inside the 'circle' to create a perfect opening. 3:25
• —Bridge the gap by creating new faces between the opening's vertices, ensuring a clean cut for the joint. 4:05
• —Extrude and flatten the edge of the new opening, then join 'pipe_1' and 'pipe_2' into a single mesh. 4:20
• —Bridge the edge loops between the two pipes and optionally dissolve unnecessary edges for a cleaner mesh. 4:32
• —Bevel the joint edge loop with multiple segments to create a smooth, seamless transition between the two pipes. 4:42
